docker 部署Flink和传统部署的详细过程

作者：❀͜͡傀儡师

Flink是一个开源的分布式流处理框架,支持状态管理、事件时间、窗口模型等特性,可以通过下载、解压、配置和启动来使用,提供了多种运行方式,包括Docker和SQLClient,本文介绍docker部署Flink和传统部署的详细过程,感兴趣的朋友跟随小编一起看看吧

简单介绍

Flink 是一个开源的、分布式的、高性能的流处理框架，主要特性有：状态管理与容错，事件时间与水位线，先进的窗口模型，轻量级的分布式快照，端到端的精确一次交付，流批一体与统一的 API，复杂的流处理拓扑与高级 API（侧输出，CEP：复杂事件处理库，Table API & SQL）等
下载地址: https://mirrors.aliyun.com/apache/flink/ z根据需求选版本

下载安装包

https://mirrors.aliyun.com/apache/flink/flink-1.20.3/flink-1.20.3-bin-scala_2.12.tgz

解压

tra -zxf flink-1.20.3-bin-scala_2.12.tgz

修改配置文件

jobmanager.rpc.address: master
jobmanager.rpc.port: 6123
jobmanager.bind-host: 0.0.0.0
jobmanager.memory.process.size: 1600m
taskmanager.bind-host: 0.0.0.0
taskmanager.host: master
taskmanager.memory.process.size: 1728m
taskmanager.numberOfTaskSlots: 2
parallelism.default: 2
jobmanager.execution.failover-strategy: region
rest.address: localhost
rest.bind-address: 0.0.0.0

启动

bin/start-cluster.sh

登录首页： http://192.168.115.102:8081

Docker Run

拉取镜像

x86架构
docker pull registry.cn-hangzhou.aliyuncs.com/qiluo-images/flink
arm架构
docker pull registry.cn-hangzhou.aliyuncs.com/qiluo-images/linux_arm64_flink
  1. 创建网络
docker network create flink-network
  1. 启动JobManager
docker run -d \
  --name=flink-jobmanager \
  --network=flink-network \
  -p 8081:8081 \
  -e FLINK_PROPERTIES="jobmanager.rpc.address: flink-jobmanager" \
  -v /data/flink:/opt/flink/data \
  registry.cn-hangzhou.aliyuncs.com/qiluo-images/flink \
  jobmanager
  1. 启动TaskManager
docker run -d \
  --name=flink-taskmanager \
  --network=flink-network \
  -e FLINK_PROPERTIES="jobmanager.rpc.address: flink-jobmanager" \
  -v /data/flink:/opt/flink/data \
  registry.cn-hangzhou.aliyuncs.com/qiluo-images/flink \
  taskmanager

带依赖的完整版本
docker-compose-full.yml

version: "3.8"
services:
  jobmanager:
    image: registry.cn-hangzhou.aliyuncs.com/qiluo-images/flink
    container_name: jobmanager
    ports:
      - "8081:8081"
      - "6123:6123"
    command: jobmanager
    environment:
      - FLINK_PROPERTIES=jobmanager.rpc.address: jobmanager
    volumes:
      - ./data/jobmanager:/opt/flink/data
      - ./logs/jobmanager:/opt/flink/log
      - ./apps:/opt/flink/apps
    networks:
      - flink-network
  taskmanager:
    image: flink:1.17.2
    container_name: taskmanager
    depends_on:
      - jobmanager
    command: taskmanager
    scale: 2
    environment:
      - FLINK_PROPERTIES=jobmanager.rpc.address: jobmanager
      - TASK_MANAGER_NUMBER_OF_TASK_SLOTS=4
    volumes:
      - ./data/taskmanager:/opt/flink/data
      - ./logs/taskmanager:/opt/flink/log
      - ./apps:/opt/flink/apps
    networks:
      - flink-network
  zookeeper:
    image: registry.cn-hangzhou.aliyuncs.com/qiluo-images/zookeeper
    container_name: zookeeper
    environment:
      - ALLOW_ANONYMOUS_LOGIN=yes
    ports:
      - "2181:2181"
    networks:
      - flink-network
  kafka:
    image: registry.cn-hangzhou.aliyuncs.com/qiluo-images/kafka
    container_name: kafka
    depends_on:
      - zookeeper
    environment:
      - KAFKA_CFG_ZOOKEEPER_CONNECT=zookeeper:2181
      - KAFKA_CFG_ADVERTISED_LISTENERS=PLAINTEXT://kafka:9092
      - ALLOW_PLAINTEXT_LISTENER=yes
    ports:
      - "9092:9092"
    networks:
      - flink-network
networks:
  flink-network:
    driver: bridge
volumes:
  flink-data:

使用SQL Client的完整环境
docker-compose-sql.yml

version: "3.8"
services:
  jobmanager:
    image: registry.cn-hangzhou.aliyuncs.com/qiluo-images/flink
    container_name: flink-jobmanager
    ports:
      - "8081:8081"
      - "6123:6123"
    command: jobmanager
    environment:
      - FLINK_PROPERTIES=
          jobmanager.rpc.address: jobmanager
          taskmanager.numberOfTaskSlots: 4
          parallelism.default: 2
    volumes:
      - ./data/jobmanager:/opt/flink/data
      - ./logs/jobmanager:/opt/flink/log
    networks:
      - flink-network
  taskmanager:
    image: registry.cn-hangzhou.aliyuncs.com/qiluo-images/flink
    container_name: flink-taskmanager
    depends_on:
      - jobmanager
    command: taskmanager
    scale: 2
    environment:
      - FLINK_PROPERTIES=
          jobmanager.rpc.address: jobmanager
          taskmanager.numberOfTaskSlots: 4
          parallelism.default: 2
    volumes:
      - ./data/taskmanager:/opt/flink/data
      - ./logs/taskmanager:/opt/flink/log
    networks:
      - flink-network
  sql-client:
    image: registry.cn-hangzhou.aliyuncs.com/qiluo-images/flink
    container_name: flink-sql-client
    depends_on:
      - jobmanager
    command: |
      bash -c "
      echo 'Waiting for Flink cluster to be ready...'
      while ! nc -z jobmanager 8081; do
        sleep 1
      done
      echo 'Starting SQL Client...'
      ./bin/sql-client.sh"
    volumes:
      - ./sql-scripts:/opt/flink/sql-scripts
    networks:
      - flink-network
    tty: true
    stdin_open: true
networks:
  flink-network:
    driver: bridge
