Nginx中间件入门指南

worker_processes 4;
events {
	worker_connections 1024;
}
http {
	upstream backend {
		server 192.168.159.130:9002 weight=2;//可以是任意的服务器地址  不一定是本机的
		server 192.168.159.130:9003 weight=2;
	}
	server {
		listen 9000;
		location / {//路由规则
            #root /home/king/share/nginx/html9000/;
			proxy_pass http://backend;   # ...转发给 backend 服务器池处理
		}
	}
	server {
		listen 9001;
		location / {
                        root /home/king/share/nginx/html9001/;# ...由本机文件系统处理
                }
	}
	server {
		listen 9002;
		location / {
                        root /home/king/share/nginx/html9002/;
                }
	}
	server {
		listen 9003;
		location / {
                        root /home/king/share/nginx/html9003/;
                }
	}
}

worker_processes 1024;

#include "ngx_config.h"
#include "ngx_conf_file.h"
#include "nginx.h"
#include "ngx_core.h"
#include "ngx_string.h"
#include "ngx_palloc.h"
#include "ngx_array.h"
#include "ngx_hash.h"
#define unused(x)  x=x
volatile ngx_cycle_t  *ngx_cycle;
void ngx_log_error_core(ngx_uint_t level, ngx_log_t *log, ngx_err_t err,
    const char *fmt, ...) {    //日志模块调用
	unused(level);
	unused(log);
	unused(err);
	unused(fmt);
}
void print_pool(ngx_pool_t *pool) {
	printf("\nlast: %p, end: %p\n", pool->d.last, pool->d.end);
}
int main() {
#if 0
	ngx_str_t name = ngx_string("King");    //string数据结构使用
	printf("name --> len: %ld, data: %s\n", name.len, name.data);
#elif 0
	ngx_pool_t *pool = ngx_create_pool(4096, NULL);    //ngx_pool_t   内存池使用
	print_pool(pool);
	int *p1 = ngx_palloc(pool, sizeof(int));
	print_pool(pool);
	void *p2 = ngx_palloc(pool, 0x10);
	print_pool(pool);
	void *p3 = ngx_palloc(pool, 0x15);
	print_pool(pool);
	ngx_destroy_pool(pool);
#else
#endif
}

#include <ngx_config.h>
#include <ngx_core.h>
#include <ngx_http.h>
typedef struct {
	ngx_flag_t enable;    # 是否启用模块（0/1）
} ngx_http_prefix_filter_conf_t;
typedef struct {
	ngx_int_t add_prefix;    #标记是否需要插入前缀（0=不插入，1=需要插入，2=已插入）
} ngx_http_prefix_filter_ctx_t;
三个核心处理函数
static ngx_int_t ngx_http_prefix_filter_init(ngx_conf_t *cf);
static ngx_int_t ngx_http_prefix_filter_header_filter(ngx_http_request_t *r);
static ngx_int_t ngx_http_prefix_filter_body_filter(ngx_http_request_t *r, ngx_chain_t *in);
static ngx_str_t filter_prefix = ngx_string("<h2>Author : King</h2><p><a href=\"http://www.0voice.com\">0voice</a></p>");
static void *ngx_http_prefix_filter_create_conf(ngx_conf_t *cf) {
#创建一个独立的配置结构体，并初始化默认值。
	ngx_http_prefix_filter_conf_t *conf = ngx_pcalloc(cf->pool, sizeof(ngx_http_prefix_filter_conf_t));
	if (conf == NULL) {
		return NULL;
	}
	conf->enable = NGX_CONF_UNSET;
	return conf;
}
static char *ngx_http_prefix_filter_merge_conf(ngx_conf_t *cf, void *parent, void *child) {#继承配置
	ngx_http_prefix_filter_conf_t *prev = (ngx_http_prefix_filter_conf_t*)parent;// 父配置（如 server 块）
	ngx_http_prefix_filter_conf_t *conf = (ngx_http_prefix_filter_conf_t*)child;// 子配置（如 location 块）
    // 合并规则：如果子配置未设置，则继承父配置的值
	ngx_conf_merge_value(conf->enable, prev->enable, 0);
	return NGX_CONF_OK;
}
static ngx_command_t ngx_http_prefix_filter_commands[] = {
#conf中可用的指令
	{
		ngx_string("add_prefix"), # 指令名
		NGX_HTTP_MAIN_CONF|NGX_HTTP_SRV_CONF|NGX_HTTP_LOC_CONF|NGX_HTTP_LMT_CONF|NGX_CONF_FLAG,#指令可能出现的在conf中的部分
		ngx_conf_set_flag_slot,    #遇到命令的时候执行这个set函数
		NGX_HTTP_LOC_CONF_OFFSET,    #读取到conf中add_prefix值后，存储的位置（location 级别）
		offsetof(ngx_http_prefix_filter_conf_t, enable),    #具体存储在结构体的哪个位置
		NULL
	},
	ngx_null_command //结尾标识
};
static ngx_http_module_t ngx_http_prefix_filter_module_ctx = {
	NULL,
	ngx_http_prefix_filter_init,    #读完最后一行conf时执行此回调函数
	NULL,    #解析到主模块 执行此回调函数
	NULL,     // 初始化主配置
	NULL,    #解析到server块 执行此回调函数
	NULL,     // server配置继承
	ngx_http_prefix_filter_create_conf,    #解析到location块 执行此回调函数 会创建一个独立的配置结构体，并初始化默认值
	ngx_http_prefix_filter_merge_conf    //location配置继承
};
ngx_module_t ngx_http_prefix_filter_module = {    #模块属性
	NGX_MODULE_V1,
	&ngx_http_prefix_filter_module_ctx,    #模块上下文
	ngx_http_prefix_filter_commands,    #模块的命令
	NGX_HTTP_MODULE,    #模块的类型
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NGX_MODULE_V1_PADDING
};
static ngx_http_output_header_filter_pt ngx_http_next_header_filter;
static ngx_http_output_body_filter_pt ngx_http_next_body_filter;
Nginx 处理 HTTP 响应时，会依次调用两类 Filter：​Header Filter​：处理响应头；​Body Filter​：处理响应体（如修改 HTML 内容）。这些 Filter 以链表形式组织，下面是头插法插入我们的Header Filter与Body Filter。
static ngx_int_t ngx_http_prefix_filter_init(ngx_conf_t *cf) {
	ngx_http_next_header_filter = ngx_http_top_header_filter;
	ngx_http_top_header_filter = ngx_http_prefix_filter_header_filter;
	ngx_http_next_body_filter = ngx_http_top_body_filter;
	ngx_http_top_body_filter = ngx_http_prefix_filter_body_filter;
	return NGX_OK;
}
static ngx_int_t ngx_http_prefix_filter_header_filter(ngx_http_request_t *r) {
#检查并标记请求
	ngx_http_prefix_filter_ctx_t *ctx;
	ngx_http_prefix_filter_conf_t *conf;
	if (r->headers_out.status != NGX_HTTP_OK) {
		return ngx_http_next_header_filter(r);
	}
     // 获取模块配置
	ctx = ngx_http_get_module_ctx(r, ngx_http_prefix_filter_module);
	if (ctx) {
		return ngx_http_next_header_filter(r);
	}
    // 检查是否已处理过（防止重复处理）
	conf = ngx_http_get_module_loc_conf(r, ngx_http_prefix_filter_module);
	if (conf == NULL) {
		return ngx_http_next_header_filter(r);
	}
	if (conf->enable == 0) {
		return ngx_http_next_header_filter(r);
	}
    // 为需要加入的前缀  分配空间，随后把这个指针和当前的HTTP请求绑定
	ctx = ngx_pcalloc(r->pool, sizeof(ngx_http_prefix_filter_ctx_t));
	if (ctx == NULL) {
		return NGX_ERROR;
	}
	ctx->add_prefix = 0;
	ngx_http_set_ctx(r, ctx, ngx_http_prefix_filter_module);
    // 仅对 text/html 响应插入前缀
	if (r->headers_out.content_type.len >= sizeof("text/html") - 1
		&& ngx_strncasecmp(r->headers_out.content_type.data, (u_char*)"text/html", sizeof("text/html")-1) == 0) {
		ctx->add_prefix = 1;// 标记需要插入前缀
		if (r->headers_out.content_length_n > 0) {
			r->headers_out.content_length_n += filter_prefix.len;// 修正 Content-Length
		}
	}
	return ngx_http_prefix_filter_header_filter(r);
}
static ngx_int_t ngx_http_prefix_filter_body_filter(ngx_http_request_t *r, ngx_chain_t *in) {
#插入前缀内容
	ngx_http_prefix_filter_ctx_t *ctx = ngx_http_get_module_ctx(r, ngx_http_prefix_filter_module);
	if (ctx == NULL || ctx->add_prefix != 1) {
		return ngx_http_next_body_filter(r, in);
	}
	#标记已处理
	ctx->add_prefix = 2;
    # 创建包含前缀内容的缓冲区，存放预设的前缀文本（filter_prefix）
	ngx_buf_t *b = ngx_create_temp_buf(r->pool, filter_prefix.len);
	b->start = b->pos = filter_prefix.data;
	b->last = b->pos + filter_prefix.len;
    # 将前缀缓冲区插入到响应体链表的头部
	ngx_chain_t *cl = ngx_alloc_chain_link(r->pool);
	cl->buf = b;
	cl->next = in;
	return ngx_http_next_body_filter(r, cl);
}

#模块的名字
ngx_addon_name=ngx_http_prefix_filter_module
#Makefile中的关键字  在其后面加上我们的库
HTTP_FILTER_MODULES="$HTTP_FILTER_MODULES ngx_http_prefix_filter_module"
#源文件的路径
NGX_ADDON_SRCS="$NGX_ADDON_SRCS $ngx_addon_dir/ngx_http_prefix_filter_module.c"

#include <ngx_http.h>
#include <ngx_config.h>
#include <ngx_core.h>
/*
#include <arpa/inet.h>
#include <netinet/in.h>
*/
#define ENABLE_RBTREE	1
#读到关键字的时候调用 用于指定handler函数 和 创建共享内存区并指定其初始化回调函数
static char *ngx_http_pagecount_set(ngx_conf_t *cf, ngx_command_t *cmd, void *conf);
#有请求的时候调用，加锁统计当前客户端 IP 的访问次数，并生成统计页面返回给用户
static ngx_int_t ngx_http_pagecount_handler(ngx_http_request_t *r);
#读到location模块调用，为每个 location 创建并初始化配置结构体
static void  *ngx_http_pagecount_create_location_conf(ngx_conf_t *cf);
#开启/reload Nginx时候调用，初始化共享内存区的回调函数
static ngx_int_t ngx_http_pagecount_shm_init (ngx_shm_zone_t *zone, void *data);
#在handler中的lookup函数中调用，自定义红黑树的插入规则
static void ngx_http_pagecount_rbtree_insert_value(ngx_rbtree_node_t *temp,
        ngx_rbtree_node_t *node, ngx_rbtree_node_t *sentinel);
#在handler中调用，遍历红黑树统计数量
static int ngx_encode_http_page_rb(ngx_http_pagecount_conf_t *conf, char *html);
#在handler中调用，对于一个新key(ip)的处理
static ngx_int_t ngx_http_pagecount_lookup(ngx_http_request_t *r, ngx_http_pagecount_conf_t *conf, ngx_uint_t key);
static ngx_command_t count_commands[] = {
	{//告诉Nginx  conf中的count是关键字，并且指定其处理函数set
		ngx_string("count"),
		NGX_HTTP_LOC_CONF | NGX_CONF_NOARGS,    //指令可以出现的位置
		ngx_http_pagecount_set,         //读到conf中的count指令时调用
		NGX_HTTP_LOC_CONF_OFFSET,
		0, NULL
	},
	ngx_null_command
};
static ngx_http_module_t count_ctx = {
	NULL,
	NULL,
    //没用上了 因为handler和共享内存池（包括红黑树）都在set函数里创建并且绑定回调了，Nginx启动的时候会自动调用回调
	NULL,
	NULL,
	NULL,
	NULL,
	ngx_http_pagecount_create_location_conf,	//读到location配置时调用，确保每个 location 都有独立的配置空间
	NULL,
};
//ngx_http_count_module   最先编写的内容
ngx_module_t ngx_http_pagecount_module = {
	NGX_MODULE_V1,
	&count_ctx,
	count_commands,
	NGX_HTTP_MODULE,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NULL,
	NGX_MODULE_V1_PADDING
};
typedef struct {
	int count;
} ngx_http_pagecount_node_t;
typedef struct {	//共享内存中的 “数据区”红黑树
	ngx_rbtree_t rbtree;
	ngx_rbtree_node_t sentinel;
} ngx_http_pagecount_shm_t;
typedef struct	//location 级别的配置结构体
{
    ssize_t shmsize;
    ngx_slab_pool_t *shpool;
    ngx_http_pagecount_shm_t *sh;
} ngx_http_pagecount_conf_t;
ngx_int_t ngx_http_pagecount_shm_init (ngx_shm_zone_t *zone, void *data) {
//zone：Nginx 共享内存区对象，包含分配好的内存地址等信息。
//data：上一次初始化时的配置数据
	ngx_http_pagecount_conf_t *conf;
	ngx_http_pagecount_conf_t *oconf = data;
	conf = (ngx_http_pagecount_conf_t*)zone->data;
	if (oconf) {//已经初始化过了  复用红黑树和 slab 内存池指针
		conf->sh = oconf->sh;
		conf->shpool = oconf->shpool;
		return NGX_OK;
	}
	//没初始化过  新建红黑树和 slab 内存池
	conf->shpool = (ngx_slab_pool_t*)zone->shm.addr;
	conf->sh = ngx_slab_alloc(conf->shpool, sizeof(ngx_http_pagecount_shm_t));
	if (conf->sh == NULL) {
		return NGX_ERROR;
	}
    //绑定红黑树  到Nginx内置new slab 内存池
	conf->shpool->data = conf->sh;
	//初始化红黑树
	ngx_rbtree_init(&conf->sh->rbtree, &conf->sh->sentinel,
		ngx_http_pagecount_rbtree_insert_value);
	return NGX_OK;
}
static char *ngx_http_pagecount_set(ngx_conf_t *cf, ngx_command_t *cmd, void *conf) {
	ngx_shm_zone_t *shm_zone;
	ngx_str_t name = ngx_string("pagecount_slab_shm");
	ngx_http_pagecount_conf_t *mconf = (ngx_http_pagecount_conf_t*)conf;
    //创建Nginx内置的配置结构体corecf
	ngx_http_core_loc_conf_t *corecf;
	mconf->shmsize = 1024*1024;
    //创建一个名为 pagecount_slab_shm 的共享内存区(通过ngx内置的共享内存管理函数  )
	shm_zone = ngx_shared_memory_add(cf, &name, mconf->shmsize, &ngx_http_pagecount_module);
	if (NULL == shm_zone) {
		return NGX_CONF_ERROR;
	}
	//把创建的共享内存区初始化
	shm_zone->init = ngx_http_pagecount_shm_init;
	shm_zone->data = mconf;
    //获取Nginx内置的配置空间，在里面设置handler，让Nginx知道遇到HTTP请求时调用我们写的处理函数
	corecf = ngx_http_conf_get_module_loc_conf(cf, ngx_http_core_module);
	corecf->handler = ngx_http_pagecount_handler;
	return NGX_CONF_OK;
}
void  *ngx_http_pagecount_create_location_conf(ngx_conf_t *cf) {
//为每个 location 创建并初始化配置结构体
	ngx_http_pagecount_conf_t *conf;
	conf = ngx_palloc(cf->pool, sizeof(ngx_http_pagecount_conf_t));
	if (NULL == conf) {
		return NULL;
	}
	conf->shmsize = 0;
	return conf;
}
static void
ngx_http_pagecount_rbtree_insert_value(ngx_rbtree_node_t *temp,
        ngx_rbtree_node_t *node, ngx_rbtree_node_t *sentinel)
{
//自定义红黑树的插入规则，据节点的 key（IP 地址的数值）决定插入到树的哪个位
   ngx_rbtree_node_t **p;
    for (;;)
    {
        if (node->key < temp->key)
        {
            p = &temp->left;
        }
        else if (node->key > temp->key) {
           	p = &temp->right;
        }
        else
        {
          	return ;
        }
        if (*p == sentinel)
        {
            break;
        }
        temp = *p;
    }
    *p = node;
    node->parent = temp;
    node->left = sentinel;
    node->right = sentinel;
    ngx_rbt_red(node);
}
static ngx_int_t ngx_http_pagecount_lookup(ngx_http_request_t *r, ngx_http_pagecount_conf_t *conf, ngx_uint_t key) {
//在红黑树中查找指定 key（IP），如果找到则计数加一；如果没找到则插入新节点并初始化计数为 1
	ngx_rbtree_node_t *node, *sentinel;
	node = conf->sh->rbtree.root;
	sentinel = conf->sh->rbtree.sentinel;
	ngx_log_error(NGX_LOG_EMERG, r->connection->log, ngx_errno, " ngx_http_pagecount_lookup 111 --> %x\n", key);
	while (node != sentinel) {
		if (key < node->key) {
			node = node->left;
			continue;
		} else if (key > node->key) {
			node = node->right;
			continue;
		} else { // key == node
			node->data ++;
			return NGX_OK;
		}
	}
	ngx_log_error(NGX_LOG_EMERG, r->connection->log, ngx_errno, " ngx_http_pagecount_lookup 222 --> %x\n", key);
	// insert rbtree
	node = ngx_slab_alloc_locked(conf->shpool, sizeof(ngx_rbtree_node_t));
	if (NULL == node) {
		return NGX_ERROR;
	}
	node->key = key;
	node->data = 1;
	ngx_rbtree_insert(&conf->sh->rbtree, node);
	ngx_log_error(NGX_LOG_EMERG, r->connection->log, ngx_errno, " insert success\n");
	return NGX_OK;
}
static int ngx_encode_http_page_rb(ngx_http_pagecount_conf_t *conf, char *html) {
//遍历红黑树，将所有 IP 及其访问次数以 HTML 格式输出到字符串 html，用于页面展示
	sprintf(html, "<h1>67777 </h1>");
	strcat(html, "<h2>");
	ngx_rbtree_node_t *node = ngx_rbtree_min(conf->sh->rbtree.root, conf->sh->rbtree.sentinel);
	do {//遍历红黑树节点
		char str[INET_ADDRSTRLEN] = {0};
		char buffer[128] = {0};
		sprintf(buffer, "req from : %s, count: %d
",
		inet_ntop(AF_INET, &node->key, str, sizeof(str)), node->data);
		strcat(html, buffer);
		node = ngx_rbtree_next(&conf->sh->rbtree, node);
	} while (node);
	strcat(html, "</h2>");
	return NGX_OK;
}
static ngx_int_t ngx_http_pagecount_handler(ngx_http_request_t *r) {
	// HTTP 请求的处理函数，统计当前客户端 IP 的访问次数，并生成统计页面返回给用户
	u_char html[1024] = {0};
	int len = sizeof(html);
	ngx_rbtree_key_t key = 0;
	struct sockaddr_in *client_addr =  (struct sockaddr_in*)r->connection->sockaddr;
	ngx_http_pagecount_conf_t *conf = ngx_http_get_module_loc_conf(r, ngx_http_pagecount_module);
	key = (ngx_rbtree_key_t)client_addr->sin_addr.s_addr;
	ngx_log_error(NGX_LOG_EMERG, r->connection->log, ngx_errno, " ngx_http_pagecount_handler --> %x\n", key);
    //先对共享内存池加锁，保证多进程/多线程安全（共享内存池自带的锁）
	ngx_shmtx_lock(&conf->shpool->mutex);
	ngx_http_pagecount_lookup(r, conf, key);
	ngx_shmtx_unlock(&conf->shpool->mutex);
	ngx_encode_http_page_rb(conf, (char*)html);
	//header
	r->headers_out.status = 200;
	ngx_str_set(&r->headers_out.content_type, "text/html");
	ngx_http_send_header(r);
	//body
	ngx_buf_t *b = ngx_pcalloc(r->pool,  sizeof(ngx_buf_t));
	ngx_chain_t out;
	out.buf = b;
	out.next = NULL;
	b->pos = html;
	b->last = html+len;
	b->memory = 1;
	b->last_buf = 1;
	return ngx_http_output_filter(r, &out);
}

http {
    //定义了一个后端服务器组，包含两个服务器
	upstream backend {
		server 192.168.159.130:9002 weight=2;//可以是任意的服务器地址  不一定是本机的
		server 192.168.159.130:9003 weight=2;
	}
	server {
		listen 9000;
		location / {//路由规则
            #root /home/king/share/nginx/html9000/;
			proxy_pass http://backend;   # ...转发给 backend 服务器池处理
	}
}
