前端Vue3图像编辑功能实现代码(并生成mask图)

<template>
  <div class="img-edit-box">
    <div class="img-edit-box-top" v-if="currentImgEdit == 'all'">
      <div class="img-edit-btn-box" @click="quoteImgEditChange">
        <!-- @click="
          quoteChange(true, currentImgUrl, 'imageEdit', currentImgQuestion)
        " -->
        <div class="img-edit-btn-zhineng"></div>
        <div class="img-edit-btn-text">智能编辑</div>
      </div>
      <div class="img-edit-btn-box" @click="changeEditStatus('scope')">
        <div class="img-edit-btn-chonghui"></div>
        <div class="img-edit-btn-text">区域重绘</div>
      </div>
      <!-- <div class="img-edit-btn-box">
            <div class="img-edit-btn-kuotu"></div>
            <div class="img-edit-btn-text">扩图</div>
          </div> -->
      <!-- <div class="img-edit-btn-box">
            <div class="img-edit-btn-cachu"></div>
            <div class="img-edit-btn-text">擦除</div>
          </div> -->
      <div class="img-edit-btn-right to-right">
        <div
          class="img-edit-btn-box"
          @click="downloadBase64"
        >
          <div class="img-edit-btn-download"></div>
          <div class="img-edit-btn-text">下载原图</div>
        </div>
        <div class="divide-line"></div>
        <div class="img-edit-btn-box close-box" @click="closeImgEditVisible">
          <div class="close-icon"></div>
        </div>
      </div>
    </div>
    <div v-if="currentImgEdit == 'scope'" class="img-edit-box-top flex-center">
      <div class="img-edit-btn-left">
        <div
          class="img-edit-btn-box close-box"
          @click="changeEditStatus('all')"
        >
          <div class="back-icon"></div>
        </div>
      </div>
      <div class="img-edit-btn-center">
        <!-- <div class="img-edit-btn-box">
              <div class="img-edit-btn-download"></div>
            </div> -->
        <div class="img-edit-btn-slider">
          <el-slider
            v-model="circleDiameter"
            :min="30"
            :max="100"
            input-size="mini"
            @mousedown="clickCircleDiameter"
            @change="changeCircleDiameter"
            @input="inputCircleDiameter"
          ></el-slider>
        </div>
        <div class="divide-line"></div>
        <div
          class="close-box"
          :class="[step == 0 ? 'img-edit-btn-box-none' : 'img-edit-btn-box']"
          @click="undo"
        >
          <div class="chexiao-icon"></div>
        </div>
        <div
          class="close-box"
          :class="[
            step == history.length - 1
              ? 'img-edit-btn-box-none'
              : 'img-edit-btn-box',
          ]"
          @click="redo"
        >
          <div class="huanyuan-icon"></div>
        </div>
        <div class="divide-line"></div>
        <div
          :class="[step == 0 ? 'img-edit-btn-box-none' : 'img-edit-btn-box']"
          style="width: max-content"
          @click="clearCanvas"
        >
          清除
        </div>
        <!-- <div
              :class="[
                step == 0 ? 'img-edit-btn-box-none' : 'img-edit-btn-box',
              ]"
              style="width: max-content"
              @click="exportMaskImage"
            >
              导出
            </div> -->
      </div>
      <div class="img-edit-btn-right"></div>
    </div>
    <div class="img-edit-box-content">
      <div class="img-preview-container" v-if="currentImgEdit == 'all'">
        <img class="img-background" :src="currentImgUrl" />
      </div>
      <div
        v-if="currentImgEdit != 'all'"
        ref="canvas_panelRef"
        class="img-preview-container"
      >
        <!-- <img ref="currentImgUrlRef" v-show="false" class="img-background" src="@/assets/image/test.png" /> -->
        <div class="img-preview-container-box" ref="imgPreviewContainerRef">
          <canvas ref="currentImgUrlCanvasRef"></canvas>
          <canvas ref="currentMaskCanvasRef"></canvas>
          <canvas ref="currentPanCanvasRef"></canvas>
        </div>
      </div>
    </div>
  </div>
</template>

<script setup>
import { nextTick } from "vue";
import { encryptText, decryptText } from "@/utils/crypto.js";
import { inject } from "vue";
const currentImgEdit = inject("currentImgEdit");
const showSend = inject("showSend");
const showSendRef = inject("showSendRef");
const props = defineProps({
  currentImgUrl: String,
});

// 更改图片编辑状态
// canvas相关代码
const canvas_panelRef = ref();
const imgPreviewContainerRef = ref();
const currentImgUrlCanvasRef = ref();
const currentMaskCanvasRef = ref();
const currentPanCanvasRef = ref();
let context = null; //背景图
let paintingContext = null; //paintingContext
let panContext = null; //panContext
let painting = false;
const brushSize = ref(5); // 笔刷大小
let mouseX = 0; // 鼠标 X 坐标
let mouseY = 0; // 鼠标 Y 坐标
let lastX = 0;
let lastY = 0;
let ratio = 0;
const canvasRect = ref({ top: 0, left: 0, width: 0, height: 0 });
const circleDiameter = ref(50); // 圆圈直径
const maxDiameter = 100; // 最大直径
const minDiameter = 30; // 最小直径
let isPanLeave = true;
let tempCanvas = document.createElement("canvas");
let tempContext = tempCanvas.getContext("2d");
let history = ref([]); // 存储画布的历史状态
let step = ref(0); // 当前状态的索引，初始为 -1 表示没有历史记录

const clickCircleDiameter = () => {
  console.log("clickCircleDiameter");
  mouseX = currentPanCanvasRef.value.width / 2;
  mouseY = currentPanCanvasRef.value.height / 2;
  drawCircle();
};
const changeCircleDiameter = () => {
  console.log("changeCircleDiameter");
  panContext.clearRect(
    0,
    0,
    currentPanCanvasRef.value.width,
    currentPanCanvasRef.value.height
  );
};
const inputCircleDiameter = () => {
  console.log("inputCircleDiameter");
  drawCircle();
};

const canvasOffset = {
  left: 0,
  top: 0,
};
// 获取canvas的偏移值
function getCanvasOffset() {
  const rect = currentMaskCanvasRef.value.getBoundingClientRect();
  canvasOffset.left =
    rect.left * (currentMaskCanvasRef.value.width / rect.width); // 兼容缩放场景
  canvasOffset.top =
    rect.top * (currentMaskCanvasRef.value.height / rect.height);
  console.log("canvasOffset", canvasOffset);
}
// 计算当前鼠标相对于canvas的坐标
function calcRelativeCoordinate(x, y) {
  return {
    x: x - canvasOffset.left,
    y: y - canvasOffset.top,
  };
}

// 存储数据
function saveState(data) {
  // 如果当前 step 不是最后一个状态，则删除之后的所有状态
  if (step.value < history.value.length - 1) {
    history.value = history.value.slice(0, step.value + 1);
  }
  // 将新状态添加到历史数组中
  history.value.push(data);
  step.value++; // 更新 step
}

function moveCallback(event) {
  if (!painting) {
    return;
  }
  const { clientX, clientY } = event;
  const { x, y } = calcRelativeCoordinate(clientX, clientY);
  paintingContext.lineTo(x, y);
  paintingContext.stroke();
}
function updateCanvasOffset() {
  getCanvasOffset(); // 重新计算画布的偏移值
}

// 绘制圆圈
const drawCircle = () => {
  if (!panContext) return;
  // 清空 Canvas
  panContext.clearRect(
    0,
    0,
    currentPanCanvasRef.value.width,
    currentPanCanvasRef.value.height
  );
  if (mouseX < 0 || mouseY < 0) {
    return;
  }
  // 绘制空心圆圈
  panContext.beginPath();
  panContext.arc(mouseX, mouseY, circleDiameter.value / 2, 0, Math.PI * 2);
  panContext.strokeStyle = "#ffffff"; // 边框颜色
  panContext.lineWidth = 2; // 边框宽度
  panContext.stroke();
};
// 动画循环
const animate = () => {
  if (!isPanLeave) {
    drawCircle();
  }
  requestAnimationFrame(animate);
};

function downCallback(event) {
  console.log("222222222222222221111111");
  event.preventDefault(); // 阻止默认行为
  event.stopPropagation(); // 阻止事件冒泡
  showSend.value = false;
  // 先保存之前的数据，用于撤销时恢复（绘制前保存，不是绘制后再保存）
  // 初始化临时画布
  tempCanvas.width = currentMaskCanvasRef.value.width;
  tempCanvas.height = currentMaskCanvasRef.value.height;
  tempContext.clearRect(0, 0, tempCanvas.width, tempCanvas.height);
  const data = paintingContext.getImageData(
    0,
    0,
    currentMaskCanvasRef.value.width,
    currentMaskCanvasRef.value.height
  );
  // 记录起始点
  lastX = mouseX;
  lastY = mouseY;
  // 绘制实心圆圈
  paintingContext.beginPath();
  paintingContext.arc(mouseX, mouseY, circleDiameter.value / 2, 0, Math.PI * 2);
  paintingContext.fillStyle = "rgba(0, 119, 255, 0.5)";
  // 填充圆形
  paintingContext.fill();
  painting = true;
}
// 监听鼠标移动
const handleMouseMove = (event) => {
  isPanLeave = false;
  const rect = canvasRect.value;
  mouseX = event.clientX - rect.left;
  mouseY = event.clientY - rect.top;
  if (!painting || (mouseX == lastX && mouseY == lastY)) {
    return;
  }
  // 设置混合模式
  paintingContext.globalCompositeOperation = "xor";
  // 直接在主画布上绘制线条
  paintingContext.beginPath();
  paintingContext.moveTo(lastX, lastY);
  paintingContext.lineTo(mouseX, mouseY);
  paintingContext.strokeStyle = "rgba(0, 119, 255, 0.5)"; // 固定透明度
  paintingContext.lineWidth = circleDiameter.value; // 使用 circleDiameter 作为线条宽度
  paintingContext.lineCap = "round"; // 设置线条末端为圆形
  paintingContext.stroke();
  // 更新上一个点的位置
  lastX = mouseX;
  lastY = mouseY;
};
const handleMouseUp = () => {
  if (painting) {
    // 保存当前画布状态
    const data = paintingContext.getImageData(
      0,
      0,
      currentMaskCanvasRef.value.width,
      currentMaskCanvasRef.value.height
    );
    saveState(data); // 调用 saveState 函数保存状态
    // 绘制结束，清空临时画布
    tempContext.clearRect(0, 0, tempCanvas.width, tempCanvas.height);
    painting = false;
  }
  showSendRef.value.style.top = `${event.y}px`;
  showSend.value = true;
};
const handleMouseLeave = () => {
  isPanLeave = true;
  panContext.clearRect(
    0,
    0,
    currentPanCanvasRef.value.width,
    currentPanCanvasRef.value.height
  );
};
function undo() {
  if (step.value > 0) {
    step.value--; // 回退到上一步
    const state = history.value[step.value];
    paintingContext.putImageData(state, 0, 0); // 恢复状态
  }
}
function redo() {
  if (step.value < history.value.length - 1) {
    step.value++; // 前进一步
    const state = history.value[step.value];
    paintingContext.putImageData(state, 0, 0); // 恢复状态
  }
}
function clearCanvas() {
  paintingContext.clearRect(
    0,
    0,
    currentMaskCanvasRef.value.width,
    currentMaskCanvasRef.value.height
  );
  // 存储最新的历史记录
  const data = paintingContext.getImageData(
    0,
    0,
    currentMaskCanvasRef.value.width,
    currentMaskCanvasRef.value.height
  );
  history.value = [data]; // 清空历史数组
  step.value = 0; // 重置 step
}

function createMaskImage() {
  // 创建一个临时 Canvas
  const tempCanvas = document.createElement("canvas");
  console.log('ratioratio',ratio)
  tempCanvas.width = currentMaskCanvasRef.value.width / ratio;
  tempCanvas.height = currentMaskCanvasRef.value.height / ratio;
  const tempContext = tempCanvas.getContext("2d");

  // 将主 Canvas 的内容绘制到临时 Canvas 上
  tempContext.drawImage(
    currentMaskCanvasRef.value,
    0,
    0,
    currentMaskCanvasRef.value.width,
    currentMaskCanvasRef.value.height,
    0,
    0,
    tempCanvas.width,
    tempCanvas.height
  );

  // 获取临时 Canvas 的像素数据
  const imageData = tempContext.getImageData(
    0,
    0,
    tempCanvas.width,
    tempCanvas.height
  );
  const data = imageData.data;

  // 遍历像素数据，将非透明像素设置为黑色，透明像素设置为白色
  for (let i = 0; i < data.length; i += 4) {
    const alpha = data[i + 3]; // 透明度通道
    if (alpha > 0) {
      // 非透明区域（涂抹的区域）
      data[i] = 0; // R
      data[i + 1] = 0; // G
      data[i + 2] = 0; // B
      data[i + 3] = 255; // A（不透明）
    } else {
      // 透明区域（背景）
      data[i] = 255; // R
      data[i + 1] = 255; // G
      data[i + 2] = 255; // B
      data[i + 3] = 255; // A（不透明）
    }
  }

  // 将处理后的像素数据放回临时 Canvas
  tempContext.putImageData(imageData, 0, 0);

  // 导出图片
  const image = tempCanvas.toDataURL("image/png");
  return image;
}


const changeEditStatus = (type) => {
  currentImgEdit.value = type;
  nextTick(() => {
    function resetCanvas() {
      // 创建一个 Image 对象
      let img = new Image();
      img.src = props.currentImgUrl;
      // 等待图片加载完成
      img.onload = () => {
        const imgAspectRatio = img.width / img.height;
        // imgPreviewContainerRef
        let maxWidth = 0;
        let maxHeight = 0;
        let style = window.getComputedStyle(canvas_panelRef.value);
        // 获取上内边距
        let paddingTop = parseInt(style.paddingTop, 10);
        let paddingRight = parseInt(style.paddingRight, 10);
        let paddingBottom = parseInt(style.paddingBottom, 10);
        let paddingLeft = parseInt(style.paddingLeft, 10);
        maxWidth =
          canvas_panelRef.value.clientWidth - paddingRight - paddingLeft;
        maxHeight =
          canvas_panelRef.value.clientHeight - paddingTop - paddingBottom;
        let containerWidth = img.width; // 容器初始宽度
        let containerHeight = img.height; // 容器初始高度
        // 根据图片比例调整容器宽高
          ratio = Math.min(maxWidth / img.width, maxHeight / img.height);
          containerWidth = img.width * ratio;
          containerHeight = img.height * ratio;
        // 设置容器宽高
        imgPreviewContainerRef.value.style.width = containerWidth + "px";
        imgPreviewContainerRef.value.style.height = containerHeight + "px";

        // 设置 canvas 的宽高与容器一致
        currentImgUrlCanvasRef.value.width = containerWidth;
        currentImgUrlCanvasRef.value.height = containerHeight;
        currentMaskCanvasRef.value.width = containerWidth;
        currentMaskCanvasRef.value.height = containerHeight;
        currentPanCanvasRef.value.width = containerWidth;
        currentPanCanvasRef.value.height = containerHeight;
        context = currentImgUrlCanvasRef.value.getContext("2d", {
          willReadFrequently: true,
        });
        paintingContext = currentMaskCanvasRef.value.getContext("2d", {
          willReadFrequently: true,
        });
        panContext = currentPanCanvasRef.value.getContext("2d", {
          willReadFrequently: true,
        });
        // 初始位置在 Canvas 中心
        const rect = currentPanCanvasRef.value.getBoundingClientRect();
        canvasRect.value = rect;
        mouseX = -200;
        mouseY = -200;
        // mouseX.value = currentPanCanvasRef.value.width / 2;
        // mouseY.value = currentPanCanvasRef.value.height / 2;
        context.drawImage(img, 0, 0, containerWidth, containerHeight);
        // 存储最新的历史记录
        const data = paintingContext.getImageData(
          0,
          0,
          currentMaskCanvasRef.value.width,
          currentMaskCanvasRef.value.height
        );
        history.value = [data];
        step.value = 0; // 更新 step
      };
      getCanvasOffset(); // 更新画布位置
    }

    resetCanvas();
    window.addEventListener("resize", resetCanvas);
    window.addEventListener("scroll", updateCanvasOffset); // 添加滚动条滚动事件监听器
    getCanvasOffset();
    // paintingContext.lineGap = "round";
    // paintingContext.lineJoin = "round";

    // currentMaskCanvasRef.value.addEventListener("mousedown", downCallback);
    // currentMaskCanvasRef.value.addEventListener("mousemove", moveCallback);
    // currentMaskCanvasRef.value.addEventListener("mouseleave", closePaint);

    animate();
    // 添加事件监听
    currentPanCanvasRef.value.addEventListener("mousedown", downCallback);
    currentPanCanvasRef.value.addEventListener("mousemove", handleMouseMove);
    currentPanCanvasRef.value.addEventListener("mouseup", handleMouseUp);
    currentPanCanvasRef.value.addEventListener("mouseleave", handleMouseLeave);
  });
};

import { defineEmits } from "vue";

const emits = defineEmits(["quoteImgEditChange",'downloadBase64','closeImgEditVisible']);

const quoteImgEditChange = () => {
  emits("quoteImgEditChange");
};
const downloadBase64 = () => {
  emits("downloadBase64");
};
const closeImgEditVisible = () => {
  emits("closeImgEditVisible");
};

defineExpose({
    currentPanCanvasRef,
    createMaskImage,
    changeEditStatus
});
</script>

<style lang="scss" scoped>
.img-edit-box {
  max-width: 700px;
  flex: 1;
  // background: #e5e9fa;
  background: #ffffff;
  align-items: center;
  display: flex;
  flex-direction: column;
  height: 100%;
  overflow: hidden;
  position: relative;
  box-shadow: 0 6px 10px 0 rgba(42, 60, 79, 0.1);
  transition: border-radius 0.4s ease-in-out;

  .img-edit-box-top {
    align-items: center;
    background: #ffffff;
    border-bottom: 0.5px solid rgba(0, 0, 0, 0.08);
    display: flex;
    flex-shrink: 0;
    // gap: 24px;
    height: 56px;
    padding: 0 16px;
    width: 100%;
    justify-content: flex-start;
    .img-edit-btn-slider {
      width: 80px;
      :deep(.el-slider) {
        height: unset;
      }
      :deep(.el-slider__button) {
        width: 15px;
        height: 15px;
        box-shadow:
          0 4px 6px rgba(0, 0, 0, 0.1),
          0 0 1px rgba(0, 0, 0, 0.3);
        border: none;
      }
      :deep(.el-slider__bar) {
        background-color: #242525;
      }
    }
    .img-edit-btn-box-none {
      display: flex;
      align-items: center;
      cursor: not-allowed;
      padding: 6px 8px;
      color: #d9d9d9;
      .chexiao-icon {
        width: 16px;
        height: 16px;
        background: url("../../../assets/image/chat/imageEdit/editInside/have_chexiao.png")
          no-repeat;
        background-size: 100% 100%;
        vertical-align: middle;
        padding: 6px 6px;
      }
      .huanyuan-icon {
        width: 16px;
        height: 16px;
        background: url("../../../assets/image/chat/imageEdit/editInside/have_chexiao.png")
          no-repeat;
        background-size: 100% 100%;
        vertical-align: middle;
        padding: 6px 6px;
        transform: scaleX(-1);
      }
    }
    .img-edit-btn-box {
      display: flex;
      align-items: center;
      padding: 6px 8px;
      cursor: pointer;
      .img-edit-btn-zhineng {
        width: 16px;
        height: 16px;
        background: url("../../../assets/image/chat/imageEdit/editInside/zhineng.png")
          no-repeat;
        background-size: 100% 100%;
        vertical-align: middle;
      }
      .img-edit-btn-chonghui {
        width: 16px;
        height: 16px;
        background: url("../../../assets/image/chat/imageEdit/editInside/chonghui.png")
          no-repeat;
        background-size: 100% 100%;
        vertical-align: middle;
      }
      .img-edit-btn-kuotu {
        width: 16px;
        height: 16px;
        background: url("../../../assets/image/chat/imageEdit/editInside/kuotu.png")
          no-repeat;
        background-size: 100% 100%;
        vertical-align: middle;
      }
      .img-edit-btn-cachu {
        width: 16px;
        height: 16px;
        background: url("../../../assets/image/chat/imageEdit/editInside/cachu.png")
          no-repeat;
        background-size: 100% 100%;
        vertical-align: middle;
      }
      .img-edit-btn-download {
        width: 16px;
        height: 16px;
        background: url("../../../assets/image/chat/imageEdit/editInside/download.png")
          no-repeat;
        background-size: 100% 100%;
        vertical-align: middle;
      }
      .img-edit-btn-text {
        // font-family: "Ali_Regular";
        margin-left: 4px;
        font-size: 14px;
      }
      .chexiao-icon {
        width: 16px;
        height: 16px;
        background: url("../../../assets/image/chat/imageEdit/editInside/chexiao.png")
          no-repeat;
        background-size: 100% 100%;
        vertical-align: middle;
        padding: 6px 6px;
        cursor: pointer;
      }
      .huanyuan-icon {
        width: 16px;
        height: 16px;
        background: url("../../../assets/image/chat/imageEdit/editInside/chexiao.png")
          no-repeat;
        background-size: 100% 100%;
        vertical-align: middle;
        padding: 6px 6px;
        cursor: pointer;
        transform: scaleX(-1);
      }
    }
    .close-box {
      padding: 6px;
    }
    .img-edit-btn-box:hover {
      background: rgba(0, 0, 0, 0.04);
      border-radius: 8px;
    }
    .img-edit-btn-right {
      display: flex;
      align-items: center;
      gap: 10px;
    }
    .divide-line {
      background: rgba(0, 0, 0, 0.08);
      display: inline-block;
      flex-shrink: 0;
      height: 16px;
      margin: 0 4px 0 6px;
      width: 1px;
    }
    .close-icon {
      width: 16px;
      height: 16px;
      background: url("../../../assets/image/chat/imageEdit/editInside/close.png")
        no-repeat;
      background-size: 100% 100%;
      vertical-align: middle;
      padding: 6px 6px;
      cursor: pointer;
    }
    .back-icon {
      width: 16px;
      height: 16px;
      background: url("../../../assets/image/chat/imageEdit/editInside/back.png")
        no-repeat;
      background-size: 100% 100%;
      vertical-align: middle;
      padding: 6px 6px;
      cursor: pointer;
    }
    .to-right {
      margin-left: auto;
    }
  }
  .flex-center {
    justify-content: center;
    .img-edit-btn-left {
      flex: 1;
      display: flex;
      align-items: center;
      gap: 10px;
    }
    .img-edit-btn-center {
      flex: 1;
      display: flex;
      align-items: center;
      gap: 10px;
    }
    .img-edit-btn-right {
      flex: 1;
    }
    .to-left {
      margin-right: auto;
    }
  }
  .img-edit-box-content {
    position: relative;
    width: 100%;
    height: 100%;
    .img-preview-container {
      align-items: center;
      display: flex;
      justify-content: center;
      box-sizing: border-box;
      height: 100%;
      padding: 40px;
      width: 100%;
      .img-preview-container-box {
        position: relative;
        width: 100%;
        height: 100%;
        cursor: none;
        canvas {
          padding: 0px;
          margin: 0px;
          border: 0px;
          background: transparent;
          position: absolute;
          top: 0px;
          left: 0px;
          display: block;
        }
      }
      .img-background {
        border-radius: 10px;
        display: block;
        max-height: 100%;
        max-width: 100%;
        -o-object-fit: contain;
        object-fit: contain;
      }
    }
  }
}
</style>
